ISO 9001 ISO 14001 CE

ENVIRONMENTAL PRODUCT DECLARATION

🏢

Declaration Holder

SITAN Constitution LTD

📄

Declaration Number

EPD-SITAN-2025-001

🗓️

Issue Date

17.09.2024

🛡️

Valid Until

16.09.2029

as per ISO 14025 and EN 15804+A1

SITAN®

SITAN® DESCRIPTION

The product complies with EU Regulation No. 305/2011 (CPR) and carries the CE marking for the European Union market.

Innovative foam ceramic panels based on expanded ceramic granules

Lightweight, non-combustible, moisture-resistant insulation of the next generation

            Reaction to Fire

                A1

            λ, W/(m·K)

                0.08

            MPa Strength

                ≥2.5

            Service Life, Years

                50+

TECHNICAL SPECIFICATIONS

PARAMETER	VALUE	UNIT	STANDART
Density at 23°C, 50% RH EN 1602	400-500 kg/m³	kg/m³	EN 1602
Thermal Conductivity λ₁₀ EN 12667	0.08-0.09 W/(m·K)	W/(m·K)	EN 12667
Compressive Strength EN 826	≥2.5 N/mm²	N/mm²	EN 826
Flexural Strength EN 12089	0.73-2.00 N/mm²	N/mm²	EN 12089
Water Absorption EN 1609	<15 %	%	EN 1609
Vapor Permeability EN 12572	0.13-0.25 mg/(m·h·Pa)	mg/(m·h·Pa)	EN 12572
Operating Temp. Range	-60 to +80 °C	°C
Reaction to Fire Class EN 13501-1	A1		EN 13501-1

SITAN® material properties are verified by independent accredited laboratories.

COMPOSITION & MATERIALS

        Expanded ceramic granules
        25-45%


        High-grade cement (500+)
        25-45%


        Mineral additives
        <25%


        Reinforcing fibers
        <6%


Product does not contain substances from the REACH Candidate List

Free from carcinogenic, mutagenic, or reprotoxic substances

100% environmentally safe components

SITAN® — completely safe for humans and the planet from installation to recycling

PRODUCTION PROCESS

SITAN® Production Technology

Preparation

Component mixing

Molding

Panel pressing

Drying

Thermal treatment

Finishing

Dimension calibration

30 mo. payback

80% CO₂ reduction

45% margin

ISO

Quality management system is certified according to ISO 9001:2015

All off-cut material is fully recycled during the production process

ENVIRONMENTAL PERFORMANCE

♻️

85%

Recyclability

High potential for secondary material use

🌱

Emission Class

Highest safety standard for indoor residential use

☢️

Activity Index

Natural purity with background levels below natural averages

🍃

<10µg/m³

VOC

Minimum content of volatile organic compounds

INDICATOR	VALUE	UNIT	EU NORM
Total VOC after 28 days <1000 µg/m³	<10 µg/m³	µg/m³	<1000 µg/m³
Formaldehyde <100 µg/m³	<5 µg/m³	µg/m³	<100 µg/m³
Carcinogenic substances <10 µg/m³	<1 µg/m³	µg/m³	<10 µg/m³

Application Efficiency

Facade Systems

Provides excellent thermal insulation (λ=0.08). High compressive strength (≥ 2.5 MPa) ensures facade integrity for decades.

Roofs & Terraces

Lightweight (up to 500 kg/m³) allows panels to be used in renovation without foundation reinforcement, providing A1 protection.

Foundations & Plinths

Resistance to moisture and aggressive media makes SITAN ideal for protecting underground building parts and high-humidity areas.

Fire Protection

Due to its absolute non-combustibility, SITAN is a critical element for fire barriers and insulation of escape routes.

SITAN®: New Construction Economics

Build faster, safer, more profitably!

⚡

2x Faster Installation

Large-format 2500 mm panels and vibration-free pouring reduce wall construction time by 60%

🚜

No Heavy Equipment

Low panel weight (up to 500 kg/m³) allows manual work even in hard-to-reach locations

🇪🇺

Green Grants

EU Green Deal compliance unlocks preferential lending and EU grants up to €1.2M

♻️

Zero Waste

Minimal construction waste. Offcut material is fully suitable for recycling
